PXR-34 Series
Generic Reader
- Conforms to ISO 14443A standard, supporting MIFARE? card.
- Unique ID or Block read fromat supported and programmable key value.
- Provides RS-485 communication interface for long distance installation.
- Keypad function. When working with controller, it provides unlock modes including card-swiping, keypad-pressing or card-swiping with password to unlock door.
- Case sensor detection function to enhance the system security.
Feature：
?
- Conforms to ISO 14443A standard, supporting MIFARE? card.
- Unique ID or Block read format supported and programmable key value.
- Provides RS-485 communication interface for long distance installation.
- Keypad function. When working with controller, it provides unlock models including card-swiping, keypad-pressing or card-swiping with password to unlock door.
- LCD displays date, day of week, time and reader’s status.
- Wide range of operating temperature to meet the requirements of tropical or frigid zone climate environment.
- Case sensor detection function to enhance the system security.
- Watchdog function secures system free from halting.
Specification：
| Read Format | MIFARE? (13.56 MHz) |
| Comm. Interface | RS-485 |
| Input Port | Case Sensor x 1 |
| ID Setting | DIP switch |
| Power Input | DC 12V / 1A? |
| Current Consumption | 300mA (max.) |
| Operating Temp. | 0° C~55° C / 32° F ~ 131° F |
| Relatice Humidity | 20% ~ 80% (Non-condensing) |
| Dimension | 140mm(L) x 65mm(W) x 25mm(H) |
Product?Information：
| Model | Description | Downloads |
| PXR-34MSK | RS-485，MIFARE? (13.56 MHz) keypad reader |  |
| PXR-34MSKL | RS-485(L-type)，MIFARE? (13.56 MHz) keypad reader | |
Related Resources：
| Resource | Model | Downloads |
| Quick Start Guide | PXR-34MSK | |
| Quick Start Guide | PXR-34MSKL | |
